I have Chinese copy of arduino which uses ATmega16u2 (at least that's what is written on the chip itself). When connected, it is visible in system information under USB section: Communication Device: Product ID: 0x0043 Vendor ID: 0x2341 Version: 0.01 Serial Number: Speed: Up to 12 Mb/sec Manufacturer: Arduino (www.arduino.cc) Location ID: 0x1a140000 / 6 Current Available (mA): 1000 Current Required (mA): 100 Extra Operating Current (mA): 0 Built-In: Yes But it doesn't show up in arduino program ports. I've searched a lot, and it seems that people mostly had problems with arduinos on CH340 chips. I also have one such arduino, but it works properly after installing signed drivers as.
Are there any solutions for atmega 16u2 chips? My system:.
Atmega16u2 Dfu Drivers For Mac Pro
OS X El Capitan 10.11.2 (15C50) (hackintosh if it changes anything). Arduino Uno R3 (chinese copy). Arduino soft version 1.6.7 Additional info: I've tried connecting Arduino Mega 2560 with Atmega16u2 chip and it also doesn't work Info I've got using Nick's awesome program: Atmega chip detector. Written by Nick Gammon. Version 1.17 Compiled on Jan 8 2016 at 21:35:08 with Arduino IDE 10607. Attempting to enter ICSP programming mode. Entered programming mode OK.
Signature = 0x1E 0x94 0x89 Processor = ATmega16U2 Flash memory size = 16384 bytes. LFuse = 0xFF HFuse = 0xD9 EFuse = 0xF4 Lock byte = 0xFF Clock calibration = 0x56 Bootloader in use: No EEPROM preserved through erase: No Watchdog timer always on: No Bootloader is 4096 bytes starting at 3000 Bootloader: 3000: 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 3010: 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 3020: 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF 0xFF.
Atmega16u2 Dfu Drivers For Mac Windows 10
You can use my to confirm (using another Arduino to run the sketch) if the target chip is a Atmega16u2 or not, and if so, what fuses etc. Wiring would be like this: Close-up: ICSP header (from above): You should see something like this: Atmega chip detector. Written by Nick Gammon.
Version 1.17 Compiled on Jan 3 2016 at 07:34:08 with Arduino IDE 10605. Attempting to enter ICSP programming mode. Entered programming mode OK. Signature = 0x1E 0x94 0x89 Processor = ATmega16U2 Flash memory size = 16384 bytes. LFuse = 0xEF HFuse = 0xD9 EFuse = 0xF4 Lock byte = 0xCF Clock calibration = 0x96 Bootloader in use: No EEPROM preserved through erase: No Watchdog timer always on: No Bootloader is 4096 bytes starting at 3000 Bootloader: 3000: 0x4B 0xC0 0x00 0x00 0x64 0xC0 0x00 0x00 0x62 0xC0 0x00 0x00 0x60 0xC0 0x00 0x00 3010: 0x5E 0xC0 0x00 0x00 0x5C 0xC0 0x00 0x00 0x5A 0xC0 0x00 0x00 0x58 0xC0 0x00 0x00 3020: 0x56 0xC0 0x00 0x00 0x54 0xC0 0x00 0x00 0x52 0xC0 0x00 0x00 0xEE 0xC4 0x00 0x00.
Followed several of the guides but cannot my new UNO board to install. Windows 7 OS. Dowloaded drivers from tried 0022 and 1.0 When I plug in my board I get solid green and solid orange light.
Auto hardware update fails after about 2 - 3 minutes. I go to device manager and under Other Devices I find ATmega16u2 DFU Right click-Update Driver Software navigate to the unzipped folder (previously copied to my desktop) tried it with and without include subfolders. I am careful to only navigate to root folder C: Users john Desktop arduino-0022 drivers and not go to C: Users john Desktop arduino-0022 drivers FTDI USB Drivers and when I hit Next I get message Windows was unable to install your ATmega16u2 DFU Windows could not find driver software for your device Feel like I'm doing everything right? Any help would be so appreciated. Was hoping to start playing around today. Bad board perhaps? I saw some posts that indicate the orange light should blink but mine is solid.
John Attachments problems.jpg (116.14 KiB) Viewed 5070 times Posts: 3 Joined: Mon Dec 26, 2011 6:11 pm.
